• Fully automatic scanning operation
• 102mm(4") scan width
• 1120 scans/sec by 20 scan lines
• Durable housing for added protection
• Mountable to wall
| Dimensions | 105 mm x 102 mm x 150 mm |
| (L x W x H) | 4.1 in x 4.0 in x 5.9 in |
| Weight | 400 g (14.1 oz) |
| Input Voltage | 5 VDC ±0.25 V |
| Operating Power | 900 mW (180 mA @ 5 V) |
| Standby Power | 850 mW (170 mA @ 5 V) |
| Host System Interfaces | USB, RS-232, KeyboardWedge, IBM 468xx (RS485) |
| Operating Temperature | 0°C to 40°C(32°F to 104°F) |
| Storage Temperature | -40°C to 60°C(-40°F to 140°F) |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 1.2 m (4 ft) drops |
| Environmental Sealing | Sealed to resist airborne particulate contaminants |
| Light Levels | 4842 Lux |
| Scan Pattern | Omnidirectional: 5 fields of 4 parallel lines |
| Scan Speed | Omnidirectional: 1120 scan lines per second |
| Print Contrast | 35% minimum reflectance difference |
| Pitch, Skew | 60°, 60° |
| Decode Capability | Reads standard 1D and GS1 DataBar symbologies |
