• Outstanding Compatibility
• Easy Operation
• Higher Printing Speed
• Superior Versatility
| Print method | 9-pin, Serial Impact Dot Matrix |
| Print font | 7 x 9 / 9 x 9 |
| Column Capacity | 40 / 42 or 33 / 35 |
| Character size(mm) | 1.2 (W) x 3.1 (H) / 1.6 (W) x 3.1 (H) |
| Character set | 95 Alphanumeric, 37 International, |
| 128 x 12 Graphic English, Traditional | |
| Chinese, Thai and Vietnamese | |
| Character per inch | 17.8 / 16 cpi or 14.5 / 13.3 cpi |
| Interfaces | RS-232, Bi-directional parallel, |
| Dealer Option: USB, 10 Base-T I/F | |
| Data Buffer | 4 KB or 40 bytes |
| Print Speed | 4.7 lps (at 40 columns, 16 cpi) |
| 6.0 lps (at 30 columns, 16cpi) | |
| Dimensions(mm) | 57.5 ± 0.5, 69.5 ± 0.5, |
| 76.0 ± 0.5 (W) x dia. 83.0 | |
| Thickness(mm) | 0.06 to 0.085 |
| Copy Capability | One original and one copy |
| Inked Ribbon | ERC-38 (Black, Black / Red) |
| Ribbon Life | Black : 3 x 106 characters, |
| B / R : 15 x 105 characters (Black), | |
| 75 x 104 characters (Red) | |
| Power | AC adaptor (included) |
| Power Consumption | Approx. 31 W |
| D.K.D.Function | 2 drivers |
| MTBF | 18 x 104 hours |
| MCBF | 18 x 106 lines |
| Overall Dimensions(mm) | Type A : 160 (W) x 286 (D) x 157.5 (H) |
| Type B : 160 (W) x 248 (D) x 138.5 (H) | |
| Type D : 160 (W) x 248 (D) x 138.5 (H) | |
| Weight(Approx.) | Type A : 2.7 Kg |
| Type B : 2.5 Kg | |
| Type D : 2.3 Kg | |
| EMC Standards | VCCI class A, FCC class A, CE marking, |
| AS / NZS 3548 class B | |
| Power Supply | Exclusive AC adaptor (included) |
| Factory Option | Near-end sensor |
| Option | Wall-hanging bracket WH-10 |
| Safety Standards | UL / CSA / TÜV (EN60950) |
