• Omnidirectional / parallel-line mode
• Sleep Mode with IR Activation, reduces power consumption
• Easily assembled and mounted onto various countertops and
desktops
• High performance and quality with low failure rate
• Ideal choice for small to mid-volume scanning in retail
application
| Light source | Visible Laser Diode, 650 nm ± 10 nm |
| Scan Depth of Field | 5~40cm |
| Resolution | 5 mil (0.127 mm) |
| Print Contrast Ratio | 35% minimum reflection difference |
| Scan Rate | 1,650 Scans/Lines/Sec |
| Symbologies | Auto discriminates all standard 1D codes. GS1 DataBar Omni Directional; GS1 DataBar Limited; GS1 GS1 DataBar Expanded. |
| Operating Temperature | -20°C - 40°C |
| Storage Temperature | -40°C - 60°C |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Light Level | 4842 Lux (450 foot-candles) |
| Shock / Drop | Designed to withstand 1m drops |
| Voltage | DC 5V ± 0.5V |
| Power Consumption | 1.4W (275 mA@ 5V) |
| Material | ABS |
| Interface | USB, RS232 Serial |
| Cable | 1.0 m |
| Dimension | 87 W × 98 D × 170 H (mm) |
| Weight | 382 g |
| Color | Black |
| Stand | NA |
| Safety | CE, EN55022 Class A; IEC 60950-1, IEC62471 |
| Laser Class | IEC 60825-1 ClassII |
| IP rating | - |
