• Ideal for customers with low volume of POS transactions
• Featuring Epson quality and reliability
• Printing speeds of up to 200mm/second for text and graphics
• Flexible coupon printing on receipts
| Print method | Thermal line printing |
| Print fonts(True type) | Font A 12(W) x 24(H) mm |
| Font B 9(W) x (H) mm | |
| Column Capacity | Standard: Paper width 80mm: 48/84; Paper width 58mm: 35/46 |
| 42 Column Mode: Paper width 80mn: 42/60; Paper width 58mn: 42/31 | |
| Character size(mm) | Font A: 1.25(W) x 3(H), Font B : 0.88(W) x 2.13(H) |
| Character set | 95 Alphanumeric, 18sets International, 128 x 43 Extend Graphics |
| Bar code: UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN), CODE39, ITF, | |
| CODABAR(NW-7), CODE93, CODE128, GS1-128, | |
| GS1 DataBar Two-dimensional code, PDF417, Qrcode, MaxiCode, | |
| Two-dimensional GS1 DataBar, Composite Symbology | |
| Character per inch | Font A: 16.9 cpi, Font B: 22.6 cpi |
| Interfaces | USB + Serial, USB + Parallel, Ethernet |
| Receive data buffer | 4 KB or 45 bytes |
| Print speed | Max. 200mm/sec |
| Resolution | 203 dpi x 203 dpi |
| Paper dimensions(mm) | 79.50 ± 0.50 (W) mm x dia 83.00 mm |
| 57.50 ± 0.50 (W) mm x dia 83.00 mm | |
| Power | 24 VDC ± 7% |
| Power consumption | Operating: Approx. 1.8A(Mean / Print ratio 18% with print pattern) |
| Standby: Approx. 0.1A (Mean) | |
| Power supply | External power supply( Model: PS-180) |
| Printer mechanism life | 15 million lines( printing + Paper feeding) |
| Auto cutter life | 1.5 million cuts |
| MTBF | 360,000 hours |
| MCBF | 60,000,000 lines |
| EMI and safety standard | Oceania EMI AS/NZS CSPR22 Class A |
| Standard accessories | Roll paper x 1 roll (for checking the initial movement of the printer), |
| CD-ROM (Drivers, Utility software, Manuals), Setup guide, Power button | |
| cover, Waterproof power button cover, Wall hanging bracket, Screws for | |
| wall hanging bracket, Rubber feet for vertical installation, Control panel | |
| sheet for vertical installation, 58-mm width paper guide, External power | |
| supply ( Model: PS-180), AC cable (May not be included depending on | |
| the printer model) | |
| Overall dimensions | 140mm (W) x 199mm (D) x 146mm (H) |
| Weight | 1.7kg |
