• True Bezel Free Designing
• Fanless Design with CPU of Celeron® Processor J1900
• Multi-angle Tilting ranging from 0-90 degree with dual – shaft
• Ergonomics design for the stand
• Expand peripherals as module integration
| CPU | Intel® Celeron® Processor J1900 |
| Memory | DDRIII-1600 4GB (up to 8GB) |
| Storage | 320GB HDD or up / 64G SSD (up to 256GB) |
| OS Support | Windows 7, Windows 8.1, Windows Embedded 8.1 Industry, Windows 10, Windows 10 IOT, POS Ready 7 |
| Display Size | 15" |
| Touch | 15" Bezel Free Resistive |
| Resolution | XGA 1024*768 |
| Brightness | 350cd /㎡ |
| Backlight Type | WLED |
| Contrast Ratio | 700:1 |
| Response Time | 2(Tr)/10(Td)ms |
| Viewing Angle (Up/ Down/ Left/ Right) | 70/70/80/80 |
| Video Interface | LVDS |
| I/O Port | DC IN(DC 2.5) |
| POWER ON/OFF | |
| 1×HDMI | |
| 1×VGA | |
| 2×USB2.0 | |
| 2×USB3.0 | |
| 1×LAN | |
| 1×MIC | |
| 1×LINE | |
| 3*COM(RJ45) | |
| 1*CASH DRAWER (Optional) | |
| Housing Material | Magaluma |
| Tilt Angle | 60° |
| VESA Mounting | 100*100MM |
| Dimensions (W x D x H) | 369*195*353MM |
| Packing Dimension | 460*250*410MM |
| Net Weight | 6.5kg |
| Gross weight | 9.0kg |
| Consumption | 35W（MAX） |
| Operating Temperature | 0 ℃ to 40℃ |
| Storage Temperature | -20℃ to 60℃ |
| Humidity | 20﹪~80﹪（RH） |
| Shock / Drop | Class A Package 1~20.99 lbs（0.45~9.54㎏） 30 in /（76.20㎝） |
| Power Input | AC 100-240V/50-60HZ 1.5A |
| Power Output | DC 12V/5A |
| Safety | FCC / CE / RoHS |
| IP Rating | IP54 |
| ISO Trick 1/2/3 Magnetic Stripe Reader | support |
| VFD | support |
| Second Display | 9.7" |
| Wireless | support |
| iButton | support |
| iButton+MSR | N/A |
| Finger Senor | N/A |
